Additional round shape rod type for compact size actuator that can operate in 24V power.

Rod type can install body part such as foot, trunnion, clavis and can replace with air cylinder as it is.

Product Information of RCA series

• Request for information materials

• Catalogue

• User's manual

• 2 dimensional CAD drawing

• Parametric CAD drawing

Features 1Setting various type of mounting brackets like in air cylinder.

Various type such as rod type, belt drive type, high thrust type, gripper type, or rotary type available depending on application.

Features 2Motor installation method can be selected from 3 types.

Motor installation method can be selected from 3 types of coupling, built-in (direct connection), and reverse type.
Motor mounting method was made selectable out of 3 types, putting in the maintainability and the mounting space in to account.

Features 3

Sensor is an option to check if origin return has been done.

Main function

Actuator is available in 3 types.

This offers 3 different motor mounting spec of Coupling spec/ Built-in spec/ Motor reversing spec and considering of ability to maintenance and mounting space. Please select according to specification criteria.

Rod type uses installation method like in air cylinder.

The option of body mounting bracket which is the same as in a foot, trunnion or a clevis on air cylinder was set.
The mounting bracket at the end of rod is also available in knuckle joint.

Controllers

Choosable small sized controllers based on controlling methods. Positioning ability has largely increased.

ROBO cylinder series are the new generation electromechanical system cylinders (electric actuators・electromechanical system sliders).

Variation of Main RCA Series

Same installation as mounting servo motor and air cylinder.

Slider types catalogue (PDF: 9.5 MB)

Motor Coupling TypeSA4C / SA5C / SA6C

Motor Built -in TypeSA4D / SA5D / SA6D / SS4D / SS5D / SS6D

Motor Reversing TypeSA4R / SA5R / SA6R

Rod type catalogue (PDF: 9.7 MB)

Motor Coupling TypeRA3C / RA4C

Motor Built -in TypeRA3D / RA4D

Motor Reversing TypeRA3R / RA4R

Full Length Short TypeSRA4R

Single Guide TypeRGS3C / RGS4C

Double Guide TypeRGD3C / RGD4C

Arm type catalogue (PDF: 4.6 MB)

Motor folded typeA4R/A5R/A6R
