日本SHOWA昭和技研旋转接头AC20A-8ALH
发布时间：2024-06-07
Pressure Rotary Fitting Pearl Rotary Joint AC (Duplex Inner Tube Fixed Screw-Mounted Type) (AC20A-8ALH)
Part Number: AC20A-8ALH
AC (Dual, screwed type, with fixed inner tube) is a rotary joint for supplying the medium to rotary equipment in a stable manner.
Configured Specifications
Download| Types | Fixed Duplex Inner Tube | Compatible Fluid | Water / Air / Steam / Oil |
|---|---|---|---|
| Maximum Operating Temperature(°C) | 180 | Maximum Operating Pressure(MPa) | 1.47 |
| Maximum Rotational Speed(rpm) | 300 | Connection Type | Screw Mounting Type |
| Types of Connection Screw for Elbow Side (Composite) | Rc | Types of Connection Screw for Head Side (Composite) | Rc |
| Type of Connection Thread for Rotor Side (Composite) | R | Nominal Connection Screw for Elbow Side (Composite) | 3/4B(20A) |
| Nominal Connection Screw for Head Side (Composite) | 3/4B(20A) | Mounting Screw Direction | LH (Left Screw) |
